Android allows you to use several different tools and techniques to enumerate software and configurations, and begin validating the software on your device. This cheat sheet is based on work performed on an Android TV device (we documented the steps in the article “Android TV Devices: Owned Supply Chain Security Threats”).
This information collected by the command below does not automatically validate the supply chain, but provides data that can be used for manual validation. Because Android has many versions and device configurations, the commands below may not work exactly as described here. Some of the data collected is highly dependent on whether you can “root” your Android device.
Adb (Android debugger) commands
$ adb connection 192.168.1.150
Connected to 192.168.1.150:5555
$ adb devices -l
List of connected devices
192.168.1.150:5555 Device Product:walleye Model:MBOX Device:walleye Transport_id:1
$ adb shell
Walleye:/ $
$ adb root
Restart adbd as root
$ adb shell
Walleye:/ #
$ adb shell pm list package -f
Package:/system/app/TvdVideo/TvdVideo.apk=com.softwinner.TvdVideo
Package:/system/priv-app/CtsShimPrivPrebuilt/CtsShimPrivPrebuilt.apk=com.android.cts.priv.ctsshim
Package:/system/priv-app/GoogleExtServices/GoogleExtServices.apk=com.google.android.ext.services
Package:/data/app/com.google.android.katniss-cge_xXeW17WhrGeW3nufDg==/base.apk=com.google.android.katniss
Package:/system/priv-app/TelephonyProvider/TelephonyProvider.apk=com.android.providers.telephony
Package:/system/priv-app/DynamicSysteminstallationService/DynamicSysteminstallationService.apk=com.android.dynsystem
Package:/system/priv-app/CalendarProvider/CalendarProvider.apk=com.android.providers.calendar
$ adb shell pm list package
$ adbshellpmlistpackages -f
$ adb shell pm list Packages -d
$ adb shell pm list Packages -e
$ adb shell pm list package -s
$ adb shell pm list package -3
$ adb shell pm list package -i
$ adb shell pm list package -u
$ adbshell pmlistpackages –user
Source: https://book.hacktricks.xyz/mobile-pentesting/android-app-pentesting/adb-commands
Dump flash over the network.
$ adb forward tcp:5555 tcp:5555
$ adb shell
$ sudo nc -l -p 5555 -e dd if=/dev/block/mmcblk0
Run the following command in a new terminal:
$ mkdir ~/dump
$ cd ~/dump
$ North Carolina 127.0.0.1 5555 | pv -i 0.5 > mydump.img
Mount the device disk image
Display partition list
$ sudo split mydump.img print
List all mountable partitions. They will be listed in File Explorer and you can click on the partition to mount it.
$ sudo kpartx -a -v mydump.img
Remove the device mapper and make sure all mounted partitions are unmounted.
$ sudo kpartx -d -v mydump.img
Scan your network for Android debugging (adb) ports
$ nmap -sV -p 5555 –open 192.168.1.0/24
Nmap scan report for 192.168.1.148
Host is booting (delay 0.12 seconds).
Port state service version
5555/tcp open freeciv?
One service was not recognized even though it returned data. If you know the service/version, please submit the following fingerprint to https://nmap.org/cgi-bin/submit.cgi?new-service.
SF-Port5555-TCP:V=7.94%I=7%D=1/23%Time=65AFEA8D%P=x86_64-pc-linux-gnu%r(ad
SF:bConnect,2C,”AUTH\x01\0\0\0\0\0\0\0\x14\0\0\0\x9f\t\0\0\xbe\xaa\xab\xb7
SF:\x94\xde\x92\xbd\0\^\x14c\xc0UDkPB\xb9\xf7\x80\xe7\x12\x8a”);
Get device properties
Get all properties.
$ adb shell getprop
Get the Android release number.
$ adb shell getprop ro.build.version.release
Obtain the build fingerprint from the vendor.
$ adb shell getprop ro.vendor.build.fingerprint
Get the device model.
$ adb shell getprop ro.product.model
Get the release name.
$ adb shell getprop ro.product.device
Get running apps.
$ adb shell ps | grep u0_
Service list:
$ adb shell service list
List app permissions:
$ adb shell pm list permissions -g -f
pull a log
$ adb logcat
$ adb logcat -d -f /sdcard/log.txt
$ adb pull /sdcard/log.txt
Tools and references
- Autopsy – The Android Analyzer module hasn’t been updated in a while, but parsing some items from Android devices is still supported. It also provides faster access to file system directory trees than commercially available tools. Most tools, but not Autopsy, will make you wait until the file system is visible during analysis. Also, the keyword search and engraving are top notch.
- Jadx – Android app decompiler
- Mobexler (commercial) – “Mobexler is a customized virtual machine designed to help with penetration testing of Android and iOS applications.”
- MobSF – Mobile App Static Analyzer
- Androidqf – Automates and simplifies most of the commands presented here in one utility (creating backups, logging, downloading applications, etc.).
- Apk sh – “apk.sh is a Bash script that facilitates reverse engineering Android apps and automates repetitive tasks such as pulling, decoding, rebuilding, and patching APKs.”
- Missing signs: How some brands forgot to protect critical parts of Android
- Analyze installed Android applications for security risks with Termux
